Водоустойчивая стена 40W СИД RGB SMD1921 P3.91 арендная видео-

Подробная информация о продукте:

Место происхождения:	Китай
Фирменное наименование:	SCXK
Сертификация:	CE/ROHS/FCC/ISO/UL
Номер модели:	П3.91

Оплата и доставка Условия:

Количество мин заказа:	скм 10
Цена:	лично переговорить
Упаковывая детали:	случай переклейки, случай полета, вы выбираете что вы любите.
Время доставки:	7-15 рабочих дней
Условия оплаты:	T/T, западное соединение, MoneyGram
Поставка способности:	5000скм в месяц

контакт

Подробное описание продукта

Применение:	Дисплей СИД	Цвет::	Полный цвет
Размер панели::	250кс250мм	Тангаж пиксела::	3,91
Разрешение модуля::	64*64доц	СИД::	СМД1921
Интерфейс данных::	ХУБ75	Режим привода::	1/16 течений развертки постоянн
Иньпут напряжение тока::	DC5V	потребляемая мощность::	40W (электропитание 200W для панели 4pcs)
Обновленный тариф::	3840Хз
Выделить:	Арендная стена СИД SMD1921 видео- , Арендная видео- стена P3.91 приведенная , 40W делают СИД водостойким рекламируя экраны

**P3.91 LED screen panel module Outdoor 250250mm 6464pixels 1/16 scan SMD1921 RGB Full color P3.91 LED display panel module**

Name: Водоустойчивая стена 40W СИД RGB SMD1921 P3.91 арендная видео-
Brand: Shenzhen ShiXin Display Technology Co.,Ltd
SKU: П3.91
Price: 10000.00 USD
Availability: InStock

Features

1.Standard dimension module size 250mm×250mm,cabine size 500mm×500mm,Compatible model PH3.91/PH4.81/PH5.95 and other pixel Pitch standard size cabinet design.

2.High-precision die-cast aluminum cabinet, seamless unit box,Perfect solution for both outdoor using

3.Light and strong cabinet design with quick locate handle lock canbe quickly and easily assembled in various ways, it can be used ina variety of occasions ,to meet different customer requirement for a variety of applications.

4.140-degree viewing angle assure the screen has wider view area, meet various rent environment and requirements.

5.Sophisticated materials for led lamp and IC, uniform screen, real andnatural color, high grey scale, high refresh rate to ensure the amazing photographic effects.

Module Parameter:

Pixel pitch	3.91mm
Pixel configuration	1R1G1B
LED type	3-in-1 SMD 2121
Module size	250x250mm
Module weight	0.35kg
Module resolution	64x64dots
Module quantity per cabinet	4pcs

Cabinet Parameter:

Cabinet size	500x500mm
Cabinet material	die- casting aluminum
Cabinet weight	6.5kg
Cabinet resolution	128x128 dots
Ingress protection	Front/Rear IP65/IP54

Whole Screen Parameter

Pixel density	65410dots/m²
Brightness	≥1200 cd/m²
Viewing angle	H≥120° V≥120°
Min.viewing distance	3.9m
Max.power consumption	890W/m²
Avg.power consumption	330 W/m²
Working voltage	110~220VAC±15%
Interface	HUB75
Colors	16.7millon colors
Gray level	65536
Refresh rate	≥1920Hz
MTBF	≥50000 hours
Lifespan	≥100000 hours
Operating temperature	-10℃ ~ +60℃
Storage temperature	-20℃ ~ +60℃

Control System Parameter:

Video signal (with video processor)	AV, S-video,VGA, DVI, YPbPr, HDMI, SDI, DP
Color temperature	Adjustable by software
Brightness level	256 levels, automatic adjustment by software
Control way	Computer, video-synchronous, real-time, off-line, internet etc.

Spec and Parameters:

Pixel Pitch:	3.91 mm
Pixel Configuration:	SMD2121 1R1G1B 3 in 1
Pixel density:	65536 dots/m2
Driving method:	real 1/16 scan
Viewing angle:	140°V and 140°H
Brightness:	1000 nits(cd/m²)
power consumption:	average 250 w/m2, max 600 w/m2
Cabinet Material:	Aluminum
Cabinet weight:	Aluminium 7.5kg
Standard Module size:	250mm×250mm
Standard Cabinet Size for option:	500X500mm
Working and Storage Humidity:	20-60% RH
Working Voltage:	AC 110v-220v ±10% 50-60Hz
Processing:	14bit-16bit
Refresh Rate:	>3840Hz
Working temperature:	-20°C-+60°C
Application:	indoor use
IP Rating:	IP30

company profile
Shenzhen SCXK Electronic Co.,Ltd established in 2009 and has the standard new factory, about 100 employees. We have outstanding R&D department and after-sell service workers, and separately design ability. Our product mainly included led indoor full color display, led outdoor full color display,led indoor full color display, led wireless car usd screen, poster screen,transparent screen etc.It can be used on the shopping mall, bank, bus station, train station, center of downtown, airport,school,factory,bus,taxi and so on. We adapt many methods and very good after-sell service to sell our product all over the world. Whenever and wherever we are, we always take the principle that is: professional makes good quality,good price product market to price product market to provide perfect product and service for our customers.
Водоустойчивая стена 40W СИД RGB SMD1921 P3.91 арендная видео- 0

Trade terms:

1).Payment: T/T ,ususally 30% prepayment before production, 60% balance to be paid before dleiverying,it also change according to total quantity .

2).Production lead time less 20 sqm: 7days, more than 100sqm:20days.

3).Sample can be delivered in 3days.

4).Shipping port: Guangzhou Mainland China.

5).Discounts are offered based on order quantities.

6).MOQ:1 sqm/10pcs

Our service:
1).Your inquiry related to our products or prices will be replied in 24hrs.

2).Well-trained and experienced staffs to answer all your enquires in fluent English .

3).OEM&ODM, any your customized screen we can help you to design and put into product.

4).Distributoer ship are offered for your unique design and some our current models .

5).Protection of your sales area, ideas of design and all your private information.

Q1. What is LED?
A:LED is sanded for Light Emitting Diode, a kind of semiconductor which is used to give and receive the electronic signal into infrared rays or light, using the characteristics of compound semiconductor. This is used for household appliances, remote controller, electric bulletin board, various kinds of automation appliances.

Q2. What are Pixel Pitch, Pixel Density, LED QTY, and Pixel Configuration?

A:Pixel Pitch is the distance between neighboring pixels.

Pixel Density is the quantity of pixels per square meter.

LED QTY is the quantity of LED lamps per square.

Pixel Configuration is the description of the consistence of a pixel, for instance, we use 1 red lamp, 1 green lamp, and 1 blue lamp to compose a pixel, the pixel configuration is 1R1G1B.

Q3. What are LED Type, Module size and Module resolution?

A:LED Type is the description of LED lamp, for instance, the brand, the shape in physical, the size of the lamp, etc.
Module size is the measurement of a module.
Module resolution is the number of pixels per module.

Q4. What is Drive Method, driving IC and Power supply

A:Drive Method: always we use static, 1/4 scan, 1/8 scan, 1/16 scan, the latter one contributes to less brightness than the former. We always use the static outdoor, and use the different kinds of scan indoor.

Driving IC is the generic term for several kinds of IC, that are used to control the LED lamps, and as a bridge between the control system and lamps.

Power supply: a kind of device that used as a transfer from 220V AC into 5V DC. It always seems like a box in the cabinet.

Q5. What is viewing angle?

A:Viewing angle is the maximum angle at which a display can be viewed with acceptable visual performance. It includes horizontal viewing angle and vertical viewing angle.

Q6: Do you offer guarantee for the products?

A: Yes, we offer 2-5 years warranty to our products.
