CO. электроники Шэньчжэня Shichuangxinke, Ltd
профессионал делает хорошее качество, обеспечивает совершенный продукт и обслуживание для каждого клиента.
 |
| Place of Origin: | China |
| Фирменное наименование: | SCXK |
| Сертификация: | CE,ROHS ,FCC,UL ISO2001 |
| Model Number: | SCXK-P6 |
| Minimum Order Quantity: | 1sqm can be available |
|---|---|
| Цена: | лично переговорить |
| Packaging Details: | the led display can be packaged with wooden box,paper box,flight case |
| Delivery Time: | 7-10days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram, D/P, D/A, L/C |
| Supply Ability: | 1000sqm/month. we can make the led display on time |
| cabinet size: | 768mmx768mm | Display Color: | 16.7million |
|---|---|---|---|
| usage: | video and picture usage | Drive Mode: | 1/8 scaning |
| module size: | 192mm x192mm | Color: | full color |
| resolution: | 16x16 | Control system: | synchronization and a synchronization |
| led lamp: | SMD3535 |
P6 advertisement 27777dots / qm Outdoor LED Billboard 192mm x192mm module size
What is LED?
LED is sanded for Light Emitting Diode, a kind of semiconductor which is used to give and receive the electronic signal into infrared rays or light, using the characteristics of compound semiconductor. This is used for household appliances, remote controller, electric bulletin board, various kinds of automation appliances.
What is Drive Method, driving IC and Power supply?
Drive Method: always we use static, 1/4 scan, 1/8 scan, 1/16 scan, the latter one contributes to less brightness than the former. We always use the static outdoor, and use the different kinds of scan indoor.
Driving IC is the generic term for several kinds of IC, that are used to control the LED lamps, and as a bridge between the control system and lamps.
Power supply: a kind of device that used as a transfer from 220V AC into 5V DC. It always seems like a box in the cabinet.
What is viewing angle?
Viewing angle is the maximum angle at which a display can be viewed with acceptable visual performance. It includes horizontal viewing angle and vertical viewing angle.
What are refresh rate and frame rate?
Refresh rate is the number of times a display’s image is repainted or refreshed per second. As it denotes a frequency of a process, the refresh rate is expressed in hertz. That is, a refresh rate of 75 Hz means the image is refreshed 75 times in one second.
Frame rate, or frame frequency, is the frequency (rate) at which an imaging device produces unique consecutive images called frames. The term applies equally well to computer graphics, video cameras, film cameras, and motion capture systems. Frame rate is most often expressed in frames per second (FPS), and is also expressed in progressive scan monitors as hertz (Hz).
Product Parameters
| Module Parameters | |||||
| 1 |
Pixel Pitch |
6mm | 5 | Module size(mm) | 192*192mm |
| 2 | Physical Density(dots/sqm) | 27777 | 6 | Module Resolution | 32*32 |
| 3 | LED Shape | SMD3535 | 7 | Drive Mode | 1/8 |
| 4 | LED Configuration | 1R1G1B | 8 | Operation Temperature | -20°C∼60°C |
| Cabinet Parameters | |||||
| 1 | Cabinet Size | 768mmx768mm | 9 | Brightness | ≥7500nits |
| 2 | Cabinet resolution | 96*96dots | 10 | Average power consumption(w/m²) | 500 |
| 3 | Led Chip | Epistar(From Taiwan) | 11 | Max power consumption(w/m²) | 900 |
| 4 | Cabinet material | Steel | 12 | Refresh Rate(Hz/s) | ≥2500 |
| 5 | Viewing angle | 140H/120V | 13 | IP Rating | Front:IP65,Rear:IP54 |
| 6 | Color number | 281 trillion | 14 | Working Voltage | 220-380V±10%,47∼64Hz |
| 7 | Input Power | DC5V | 15 | Display Mode | Synchronous with video source |
| 8 | Screen Life Span | ≥10000hours | 16 | Signal Communication | DVI,RS232,LAN |
| the outdoor full color led display module ( smd and dip are available) | |||||
| Number | Drive mode | Moduel size | Resolution | Led standard | pixel density |
| P4 | 1/8 scan | 256x128mm | 64x32 | 3in1 | 62500 |
| p4.81 | 1/13scan | 250x250mm | 52x52 | 3in1 | 43222 |
| p5 | 1/8 scan | 160x160mm | 32x32 | 3in1 | 40000 |
| P6 | 1/8 scan | 192x192mm | 32x32 | 3in1 | 27778 |
| P8 | 1/4scan | 256x128mm | 32x16 | 3in1 | 15625 |
| P10 | 1/4scan | 160x160mm | 16x16 | 3in1 | 10000 |
| P12 | 1/4scan | 192x192mm | 16x16 | 3in1 | 6944 |
| P16 | static scan | 256x256mm | 16x16 | 3in1 | 3906 |
| P20 | static scan | 320x160mm | 16x8 | 3in1 | 2500 |
| P25 | static scan | 200x200mm | 8x8 | 3in1 | 1600 |
| P31.25 | static scan | 250x250mm | 8x8 | 3in1 | 1024 |
Features:
1. high brightness 8000~10000nits
2. High color uniformity and clear image
3. Famous Brand chip: Epistar, IC: MBI
4. Used for meeting room,lobby of hotel ,cinema,shopping mall and station,airport, studio,stadium and studio.
Packing>>>
For iron cabinet led display screen of indoor or outdoor,we usually use wooden case to packing
For aluminum cabinet of led rental stage display,we usuallu use flight case to packing
One wooden case including 2 cabinets,one flight case including 6 cabinets
Shippment>>>
By air or sea,FOB shenzhen
UPS/DHL/Fedex/Express(door to door)and so on
Delivery time>>>
within 20 days counting from 30% prepayment arrived at Suyen account.
Payment term>>>
T/T(30% deposit,the remained 70% payment made before factory shipment )
Western union/paypal/L/C and so on
Quality assurance>>>
We offer 6 years warranty,and our products have passd CE,RoHS,FCC certificate ,All products have Age testing,s
haking testing,waterproof testing,In generally,Module test is 24h,entire screen test is 72h,A series of testing before delivery can ensure transportation and quality products.
